Gaudi XML Maxim3D Extractor

Import. Verify. Extract.

RC / Z2 / Z3 data, scleral BFS, and flat-axis prediction

Scan Setup

Load the Gaudi XML and verify the key values before extraction.

Load Gaudi XML

Eye

HVID (mm)

Auto-read from XML. Editable if needed.

Design Chords

RC chord

HVID − 3.0

Z2 chord

HVID + 0.2

Z3 chord

HVID + 2.2

Advanced Quality Settings

Sampling width ± mm

Angular bin °

Sampling width includes points within ± this distance from each chord. Angular bin groups nearby meridians before sag and axis are calculated.

Extracted Values

Review lens-design values and data quality before transferring to Maxim3D.

Status

Load a file…

—

Scleral BFS

Fit over annulus Z2 → Z3

BFS radius

—

Steep haptic

—

Flat haptic

—

Fit points

—

Scleral Flat Axis Predictor

Fit over annulus Z3 → final lens diameter

Flat axis

—

Opposite axis

—

Scleral toricity

—

Coverage

—

Annulus / points

—

Tip: if a zone shows low coverage, increase sampling width slightly, usually 0.07–0.10, or adjust the chord.
